Megger MPAC208 Pro Kit with case, camera, and verifier

MPAC208-IECEx Pro Kit

SKU: 1016-923

Hazardous-area acoustic imaging package: IECEx-certified MPAC208-IECEx camera, MPAC-V verifier and ultrasound generator, and the high-resolution 640 x 512 thermal camera module.

$28,700.00

List price. Volume pricing available.

Qty:

Authorized Dealer

Calibration Available

Nationwide Shipping

Expert Support

Hazardous-Area Acoustic Imaging Camera Pro Kit

The MPAC208-IECEx Pro Kit combines the IECEx-certified MPAC208-IECEx acoustic imaging camera with the MPAC-V verifier and ultrasound generator and the 640 x 512 thermal camera module, covering acoustic inspection, thermal correlation, and field verification in one package.

The camera provides all the capability of the standard MPAC208 and is certified for use in explosive atmospheres: a 208-channel MEMS microphone array (2 kHz to 100 kHz), a 13 MP optical camera with 8-inch touchscreen, detection at ranges up to 200 meters, and Gas Leak, Partial Discharge, and Mechanical operating modes.

Note that the MPAC-V verifier and the thermal camera module are not rated for explosive atmospheres; only the camera itself carries the IECEx certification. Use those accessories in non-hazardous areas.

Kit Contents

MPAC208-IECEx Acoustic Imaging Camera (1016-918)
MPAC-V Acoustic Camera Verifier and Ultrasound Generator (1016-919)
Thermal Camera Module, 640 x 512 (1016-921)

The Megger MPAC208-IECEx Pro Kit # 1016-923 is manufactured by Megger. Valley Instrument Service is an authorized Megger dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.

Have questions about this product?

Our team can help with product selection, specs, pricing, and application support.

This product is part of a family with 6 models. Select a model below to view details.

Model	Description	Price
MPAC128 Professional Acoustic Imaging Camera 1015-886	Professional 128-microphone acoustic imaging camera for partial discharge detection in switchgear, corona inspection, and compressed-air leak surveys. Real-time visual overlay shows ultrasonic emission sources directly on the camera image.	$15,510.00	View Details →
MPAC128-ATEX Hazardous-Area Acoustic Imaging Camera 1015-885	Hazardous-area (II 3G Ex ic IIC T5 Gc) variant of the MPAC128 professional acoustic imaging camera. Detects partial discharge in switchgear, corona, and compressed-air leaks via 128-microphone array — rated for use in explosive atmospheres on gas platforms and petrochemical sites.	$28,955.00	View Details →
MPAC208 Acoustic Imaging Camera 1016-917	Professional 208-channel acoustic imaging camera for gas leak surveys, mechanical fault diagnosis, and partial discharge detection in high-voltage systems. Real-time visual overlay shows ultrasonic sources directly on the 13 MP camera image.	$19,500.00	View Details →
MPAC208 Pro Kit 1016-922	Complete acoustic imaging package: MPAC208 professional acoustic camera, MPAC-V verifier and ultrasound generator, and the high-resolution 640 x 512 thermal camera module.	$23,100.00	View Details →
MPAC208-IECEx Hazardous-Area Acoustic Imaging Camera 1016-918	IECEx-certified version of the MPAC208 acoustic imaging camera for inspection work in explosive atmospheres. Same 208-channel microphone array, three operating modes, and real-time acoustic overlay as the standard camera.	$25,250.00	View Details →
MPAC208-IECEx Pro KitCurrent 1016-923	Hazardous-area acoustic imaging package: IECEx-certified MPAC208-IECEx camera, MPAC-V verifier and ultrasound generator, and the high-resolution 640 x 512 thermal camera module.	$28,700.00	Viewing

Accessories, replacement sensors, and parts for this product family.

Model	Description	Price
MPAC-V Acoustic Camera Verifier and Ultrasound Generator 1016-919	Field verification accessory and ultrasound generator for Megger MPAC acoustic imaging cameras. An automated routine in the camera verifies frequency response, measured sound pressure level, and microphone location calibration.	$2,450.00	View Details →
Thermal Camera Module, 384 x 288, for MPAC208 1016-920	Optional thermal imaging module with 384 x 288 resolution for the MPAC208 and MPAC208-IECEx acoustic cameras. Adds side-by-side acoustic and thermal visualization to correlate heat signatures with ultrasonic anomalies.	$2,250.00	View Details →
Thermal Camera Module, 640 x 512, for MPAC208 1016-921	Optional high-resolution thermal imaging module with 640 x 512 resolution for the MPAC208 and MPAC208-IECEx acoustic cameras. Adds side-by-side acoustic and thermal visualization to correlate heat signatures with ultrasonic anomalies.	$3,400.00	View Details →
