Detex Voltage Detector, 4.0-14.5 kV (Hot-Stick Mount)
SKU: 514360-5
Utility-grade non-contact voltage detector for verifying de-energized status on grounded AC systems, 4.0-14.5 kV operating range. Single red LED + audible beeper for clear indication of phase-to-ground voltage. Universal spline fitting attaches to a hot stick rated for the system voltage (hot stick sold separately). Conforms to IEC 61243-1 and ANSI C84.1-1982.
List price. Volume pricing available.
4.0-14.5 kV Electronic DETEX Voltage Detector
For use on any grounded electrical system, DETEX Voltage Detectors are available in seven models that cover a range from distribution class to transmission line voltages up to 550 kV. Biddle offers six electronic "beeper" models and one model with LED indication for greater visibility when testing indoors.
The beeper-style electronic detectors provide audible and visual indication of the presence of phase-to-ground ac voltages, in accordance with ANSI C84.1-1982 standards.
The 6.9-kV model is equipped with a telescopic pole. All other models are fitted for universal spline mounting on a hot line pole rated for the voltage of the system being tested.
Electronic voltage detectors for use on distribution line voltages (Cat. No. 514360 series) provide a single red LED.
Key Features
- Designed to Rigid Safety Standards, Conforms to IEC61243-1
- Contact Detection Avoids the Hazards of Extraneous Noise Pickup.
- A Loud Audible Tone and Easily Visible Red LEDs Indicate the Presence of Voltage, Keeping High-Voltage Workers Safe
The Megger Detex Voltage Detector, 4.0-14.5 kV (Hot-Stick Mount) # 514360-5 is manufactured by Megger. Valley Instrument Service is an authorized Megger dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Have questions about this product?
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681This product is part of a family with 7 models. Select a model below to view details.
| Model | Price | |
|---|---|---|
2.3-7.2 kV (Hot-Stick Mount) 514360-8 | $2,305.00 | View Details → |
3.6-36.5 kV (Indoor, White LED) 514440-3 | $2,100.00 | View Details → |
4.0-14.5 kV (Hot-Stick Mount)Current 514360-5 | $2,280.00 | Viewing |
11.7-36.2 kV (Hot-Stick Mount) 514360-6 | $2,290.00 | View Details → |
24.3-72.5 kV (Hot-Stick Mount) 514360-7 | $2,290.00 | View Details → |
67-235 kV (Hot-Stick Mount) 514242-1 | $3,415.00 | View Details → |
200-550 kV (Hot-Stick Mount) 514242-2 | $3,415.00 | View Details → |
