TRMS Digital Multimeter Model 5217 (6000-Count, K-Type Thermocouple, NCV)

SKU: 5217

The Model 5217 is a portable hand-held TRMS digital multimeter that measures voltage (AC and DC), current (AC and DC up to 10 A), resistance, capacitance, frequency, and temperature (K-type thermocouple, −67° to 2192°F). Continuity checks, non-contact voltage detection, and diode testing; Auto Range and Data HOLD on a 6000-count backlit display. IP54 ingress; 600 V CAT III; >500-hour battery life.

$130.00

List price. Volume pricing available.

Qty:

Authorized Dealer

Calibration Available

Nationwide Shipping

Expert Support

The Model 5217 is a portable hand-held multimeter that measures a variety of electrical and physical quantities including voltage (AC and DC), resistance, capacitance, frequency and temperature. These instruments can also perform continuity checks, voltage detection and diode testing (including forward bias voltage). Measurement features include Auto Range mode, which enables the instrument to select the best range for the input detected, and a Data HOLD function. These instruments are rugged and simple to use and rated to 600V CAT III.

The AEMC Instruments TRMS Digital Multimeter Model 5217 (6000-Count, K-Type Thermocouple, NCV) # 5217 is manufactured by AEMC Instruments. Valley Instrument Service is an authorized AEMC Instruments dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.

Have questions about this product?

Our team can help with product selection, specs, pricing, and application support.

This product is part of a family with 9 models. Select a model below to view details.

Model	Description	Price
5212	The Model 5212 is a portable hand-held TRMS digital multimeter that measures voltage (AC and DC), current (AC and DC up to 10 A), resistance, and capacitance. Performs continuity checks, non-contact voltage detection, and diode testing with forward-bias voltage. Auto Range and Data HOLD on a 4000-count display; rugged housing rated to 600 V CAT III.	$115.00	View Details →
5217Current	The Model 5217 is a portable hand-held TRMS digital multimeter that measures voltage (AC and DC), current (AC and DC up to 10 A), resistance, capacitance, frequency, and temperature (K-type thermocouple, −67° to 2192°F). Continuity checks, non-contact voltage detection, and diode testing; Auto Range and Data HOLD on a 6000-count backlit display. IP54 ingress; 600 V CAT III; >500-hour battery life.	$130.00	Viewing
2154.04	The Model MTX 3293B is a portable hand-held multimeter with a 100,000-count, 320×240 pixel color graphical display. Measures voltage (1000 VAC/DC), current (10 A AC/DC, 20 A for 30 s), resistance (to 100 MΩ), capacitance, frequency (10 Hz to 5 MHz), and temperature via PT100/1000 RTDs and K/J thermocouples. Dynamic recording with 30,000-measurement memory and waveform display. IP67 waterproof; 1000 V CAT III / 600 V CAT IV; USB connectivity.	$895.00	View Details →
2154.05	The Model MTX 3292B-BT is the Bluetooth-enabled variant of the MTX 3292B — same 100,000-count color graphical display and ASYC IV TRMS engine, with wireless Bluetooth connectivity alongside the standard USB port. Measures voltage (1000 VAC/DC), current (10 A AC/DC), resistance (to 100 MΩ), capacitance, frequency (10 Hz to 5 MHz), and temperature. IP67 waterproof; 1000 V CAT III / 600 V CAT IV.	$925.00	View Details →
2154.10	The Model 5115 is a professional pocket-sized digital multimeter rated to 600 V CAT III, with a built-in non-contact voltage detector and flashlight. Measures voltage (AC and DC), resistance, and continuity on a 2000-count backlit LCD. IP40 ingress rating; ships in a soft neoprene pouch with batteries installed.	$59.00	View Details →
5233	The Model 5233 is a rugged, economical TRMS digital multimeter with non-contact voltage detection (display turns red near live cables) and K-type thermocouple temperature measurement (−4° to 1400°F). Measures voltage (1000 VAC / 600 VDC), current up to 10 A direct (15 A for 60 s), resistance to 60 MΩ. 6000-count display with 61-segment analog bargraph and backlight. 600 V CAT IV; overload protection to 8000 V.	$125.00	View Details →
5231	The Model 5231 is a rugged, economical TRMS digital multimeter with non-contact voltage (NCV) detection — built for electrical installers, electricians, and HVAC technicians. Measures voltage (1000 VAC / 600 VDC), current (with 1 mV/A clamp), and resistance to 60 MΩ. 6000-count display with 61-segment analog bargraph and backlight. 1000 V CAT III / 600 V CAT IV safety; >100-hour battery life.	$89.00	View Details →
2154.01	The Model MTX 3290 is a portable hand-held multimeter that measures voltage (AC and DC, up to 1000V), current (10A AC/DC, 15A for 30 s), resistance (to 60 MΩ), capacitance (to 60 mF), temperature, and frequency (60 Hz to 600 kHz). 6000-count digital LCD with low-impedance AC voltmeter for detecting ghost voltages; Min/Max/Avg/Peak monitoring; Auto Range and Data HOLD. IP67 waterproof; 600 V CAT III / 300 V CAT IV; ~100-hour battery life on 4 AA cells.	$570.00	View Details →
2154.02	The Model MTX 3291 is a portable hand-held multimeter with a 60,000-count display that measures voltage (AC and DC, up to 1000 V), current (10 A AC/DC, 20 A for 30 s), resistance (to 60 MΩ), capacitance (to 60 mF), temperature (−328° to 1472°F), duty cycle, and frequency (60 Hz to 600 kHz). USB connectivity with SX_DMM software included. IP67 waterproof; 1000 V CAT III / 600 V CAT IV; ~100-hour battery life.	$675.00	View Details →

Accessories, replacement sensors, and parts for this product family.

Model	Description	Price
2139.71	Thermocouple - K-Thermocouple w/4mm Integrated Adapter	$14.00	View Details →
2154.74	Lead - Replacement Set of 2, Needle Tip Color-Coded (Red/Black) w/4mm Right-Angle Plug for Models 5212-5217 (Or Any Meter That Accepts 4mm Banana Plugs)	$13.25	View Details →
2154.76	Fuse - Set of 3, FF, 0.63A, 1000V, 30kA, 10x38mm for Models 5212 - 5215	$14.70	View Details →
2126.47	Thermocouple - Flexible (1M), K Type, -58° to 480° F (for use with Models SLII L642 & CA863)	$9.95	View Details →
5000.94	Lead - Set of 2, 5 ft Silicone Color-Coded (Red/Black) with 4mm Straight/Right Banana Plugs (Rated 1000V, CAT IV, UL V2)	$29.00	View Details →
5100.07	Lead - Set of 2, 5 ft PVC Color-Coded (Red/Black) w/4mm Straight/Straight Banana Plugs (Rated 1000V CAT IV, 15A, UL V2)	$25.75	View Details →
2139.74	Lead - Set of 2, 6.5 ft. Color-Coded (Rd/Bk) Fused Leads (.63A) w/4mm Banana Plugs (Use with Clamp-on Meters, DMM'S, Hand- Held Megohmmeters)	$125.00	View Details →
2152.28	Lead - Set of 2, 6.5 ft. Color-Coded (Red/Black) Fused Leads (0.63A); Two Screw-on Alligator Clips, Two Screw-on Test Probes, Set of 5, 0.63A Fuses (UL)	$219.50	View Details →
2154.75	Fuse - Set of 3, FF, 10A, 1000V, 30kA, 10x38mm for Models 5212 - 5215	$23.65	View Details →
MN05	AC Current Probe Model MN05 (100A, 1mV/A & 10A, 1mV/mA, Lead) - Model MN103	$240.00	View Details →
5000.98	Probe - Red Test Probe (1000V CAT IV, 15A, UL V2)	$9.40	View Details →
2118.09	Case - General Carrying Case (13x9.5x3")	$77.25	View Details →
2117.73	Pouch - Replacement for Models 1026, 505, 566, 5212-5217, 5231, 5233, 6608, 6609, & 6610 (8.5" x 6.75" x 2.7")	$24.00	View Details →
2119.02	Pouch - Soft Carrying Pouch (Cable Tester, Megohmmeters, Multimeters, Etc., 7.75x9.25x2.75")	$52.90	View Details →
2126.46	Thermocouple - Needle, 7.25" x 0.5" K Type, -58° to 1292° F (for use with Models SLII L642 & CA863)	$20.00	View Details →
