789/T3000 FC Connect Processmeter/Temp Measure Kit
SKU: FLUKE-789/T3000 FC
Fluke 789 ProcessMeter is wireless via Fluke Connect & combines a DMM & loop calibrator. Large, bright dual display. Get specs and buy official Fluke here. Built-in selectable 250 ohm HART resistor for communicating with HART devices.
List price. Volume pricing available.
Fluke 789 ProcessMeter is wireless via Fluke Connect & combines a DMM & loop calibrator. Large, bright dual display. Get specs and buy official Fluke here.
Key Features
- Compact digital multimeter and mA loop calibrator solution
- Full-featured mA loop calibrator with built-in 24v Loop Power
- Quickly and easily troubleshoot every part of a control loop
- Large, bright dual-measurement display
The Fluke 789/T3000 FC Connect Processmeter/Temp Measure Kit # FLUKE-789/T3000 FC is manufactured by Fluke. Valley Instrument Service is an authorized Fluke dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Have questions about this product?
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| General | Specifications |
| Range | 0-1 A DC |
| Resolution | 1 mA |
| Accuracy | 0.2% + 2 LSD |
| Accuracy (25 Hz to 2 kHz) | +/- 1% +2 LSD |
| Drive capability | 24 V Compliance or 1200 Ω @ 20 mA |
| Continuity | Beeps for resistance < 100 Ω |
| Resistance measurement | to 40 MΩ, 0.2% + 1 LSD |
| Diode test | 2.0 V shows diode voltage drop |
| Display current and % of span | Yes |
| Auto Step, Auto Ramp | Yes |
| Voltage measurement | Environmental Specifications |
| Operating temperature | -20°C to 55°C |
| Storage temperature | -40°C to 60°C |
| Humidity (without condensation) | 95% up to 30°C75% up to 40°C45% up to 50°C35% up to 55°C |
| Temperature coefficient | 0.05 x (specified accuracy) per °C (for temperatures 28°C) |
| Electrical safety | Designed in accordance with IEC 61010-1: Pollution Degree 2 |
| Overvoltage category | IEC 61010-2-033: CAT IV 600 V / CAT III 1000 V |
| Maximum voltage | 1,000 V |
| Size (H x W x L) | 50 x 100 x 203 mm (1.25 x 3.41 x 7.35 in) |
| Weight | 610 g (1.6 lbs) |
| Batteries | 4 AA alkaline batteries |
| Warranty | 3 years |
| Battery life | 140 hours typical (measurement), 10 hours typical (sourcing 20 mA) |
| Shock and vibration | Random, 2 g, 5-500 Hz1 meter drop test |
This product is part of a family with 5 models. Select a model below to view details.
| Model | Price | |
|---|---|---|
FLUKE-789 | $1,444.99 | View Details → |
FLUKE-789 CAL | $1,887.98 | View Details → |
FLUKE-789/T3000 FCCurrent | $1,897.99 | Viewing |
FLK-789/773 BU | $2,963.30 | View Details → |
FLK-789/IR3000 BU | $1,520.27 | View Details → |
