ADT286, Remote Module Docking Station w/ AC Adapter

Designed to make your job easier, the ADT286 has a large sensor library supporting 15 TC types, both standard and special limits, 18 different thermal resistors, CVD, ITS-90, and a large variety of standard curves for RTDs and thermistors. The ADT286 is loaded with special applications such as probe calibration, SPRT calibration, chamber mapping and more. And we continue to add applications on a regular basis!

The Additel 286 Multifunction Reference Thermometer Readout has preinstalled drivers to control Additel and other manufacturer’s heat sources. Simply connect to one or more heat sources via a communication cable, Ethernet or wireless and now it will automatically control to the set point and desired stability. If your heat source is not on the list, you can easily add the driver yourself so you can run automated calibrations with any heat source.

Available in 25 and 100 Ohm values, users can enjoy improved resistance ratio performance by easily plugging one of our reference resisters into channel 2 on the new ADT286. Perfect for calibrating your SPRT’s and high end PRT’s.

Key Features

• Measure and calibrate SPRTs, RTDs, thermistors and thermocouples
• 1 PPM resistance ratio accuracy (channel 1)
• 8 1/2-digit DC multimeter
• Measure up to 82 channels
• Bluetooth, WIFI, USB& Ethernet (RJ-45) capable
• Auto temperature control of Additel and other manufacture's heat sources
• Built-in automatic temperature control, data collection, and coefficient generation
• Support for creating custom control of heat sources with RS-232
• Auto - zero power feature (self heating compensation)
• 10.1 in. touch screen display
• Supports fully automated temperature calibrations with data collection and report generation (no software required)
• ISO 17025-accredited calibration w/data included

The Additel ADT286, Remote Module Docking Station w/ AC Adapter # ADT286-DOCK is manufactured by Additel. Valley Instrument Service is an authorized Additel dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
