Temperature Detection - With Current or Voltage Output and PNP/NPN Transistor Switching Output

Temperature Detection — With Current or Voltage Output and PNP/NPN Transistor Switching Output

• Processor unit for connecting sensors from the TP product series
• Automatic probe detection
• 4-digit, 2-color (red/green), 12-segment display, rotatable by 180°
• Housing upper section rotatable by 340°
• Compatible with the following temperature sensors:
• Resistance Temperature Detector (RTD) — Pt100 (2-, 3-, 4-wire) — Pt1000 (2-, 3-, 4-wire)
• Thermocouples (TC) — type K, B, E, J, N, R, S and T
• 17…33 VDC
• NO/NC contact, PNP/NPN output, analog output (current/voltage), IO-Link
• Various IO-Link mapping profiles can be selected

The Turck Temperature Detection - With Current or Voltage Output and PNP/NPN Transistor Switching Output # TS720-LI2UPN8-H1141 is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
