Absolute Rotary Encoder - Multiturn
SKU: RM-89SA1R-9B28B-B2M12
Industrial Line
$1,999.10
List price. Volume pricing available.
Authorized Dealer
Calibration Available
Nationwide Shipping
Expert Support
Absolute Rotary Encoder - Multiturn — Industrial Line
- Protection class IP67
- ‐40…+85 °C
- Max. 6000 rpm(Continuous operation 3000 rpm)
- DeviceNet
- Male 2 x M12
- Bus M12 Pin / BUS OUT M12 connector
- Singleturn, 16 bit resolution
- Multiturn, 12 bit resolution
The Turck Absolute Rotary Encoder - Multiturn # RM-89SA1R-9B28B-B2M12 is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Have questions about this product?
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| EAN | 4047101323795 |
| eCl@ss-Code (V5.1.4) | 27270501 -/- Encoder, absolute |
| Customs tariff number | 9032896085 |
| Country of origin | US |
| Weight | 739.89 g |
| Encoder line | Industrial-Line |
| Technology | Optical |
| Output type | Absolute multiturn |
| Shaft Type | Solid shaft |
| Shaft diameter D (mm) | 9.5 |
| Operating voltage | 11…25 VDC |
| Communication protocol | DeviceNet |
| Housing material | Powder-coated die-cast aluminium |
| Ambient temperature | -40…+85 °C |
| Protection class housing | IP67 |
| Protection class shaft | IP67 |
