Absolute Shaft Encoder
SKU: RM-28TA1R-3C24B-H1181/N16
Ø 63.5 mm · Synchro flange · Solid shaft · Connector, M12 × 1
$1,348.40
List price. Volume pricing available.
Authorized Dealer
Calibration Available
Nationwide Shipping
Expert Support
Absolute Shaft Encoder — Industrial Line
- Square flange, Ø 63.5 mm
- Solid shaft, Ø 9.525 mm x 22.225 mm
- Optical measuring principle
- Shaft material: stainless steel
- Protection class IP65 on shaft side
- -40…+85 °C
- Max. 12000 rpm (continuous operation 10000)
- 10…30 VDC
- SSI, gray
- M12 connector, 8-pin
- Singleturn, 12-bit resolution
- Multiturn, 12-bit resolution
The Turck Absolute Shaft Encoder # RM-28TA1R-3C24B-H1181/N16 is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Have questions about this product?
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| eCl@ss-Code (V5.1.4) | 27270501 -/- Encoder, absolute |
| Customs tariff number | 9031499000 |
| Country of origin | DE |
| Weight | 1100 g |
| Encoder line | Industrial-Line |
| Technology | Optical |
| Output type | Absolute multiturn |
| Shaft Type | Solid shaft |
| Shaft diameter D (mm) | 9.525 |
| Flange diameter | Ø 63.5 mm |
| Flange type | Synchro flange |
| Operating voltage | 10…30 VDC |
| Communication protocol | SSi |
| Electrical connection | Connector, M12 × 1 |
| Housing material | Die-cast zinc |
| Ambient temperature | -40…+85 °C |
| Protection class housing | IP67 |
| Protection class shaft | IP65 |
