Incremental Shaft Encoder - (RI-10TA0Z4-2K1000-C1M/N26)
Turck

Incremental Shaft Encoder, Clamping Flange Ø 58 mm, Solid Shaft, 1000 ppr, Push-Pull 7272, 5…30 VDC, Cable

SKU: RI-10TA0Z4-2K1000-C1M/N26

$450.00

List price.

Authorized Dealer
Calibration Available
Nationwide Shipping
Expert Support

Ø 58 mm · Clamping flange · Solid shaft · Cable

Incremental Shaft Encoder — Industrial Line

  • Clamping flange, Ø 58 mm
  • Solid shaft, Ø ¼ in × 3/8 in
  • Optical measuring principle
  • Shaft material: stainless steel
  • Protection class IP65 on shaft side
  • -40…+85 °C
  • Max. 12000 rpm (continuous operation 6000)
  • 5…30 VDC
  • Cable connection, 8-pole
  • Push-pull, with inverted signals
  • Pulse frequency max. 300 kHz
  • 1000 pulses per revolution

The Turck Incremental Shaft Encoder, Clamping Flange Ø 58 mm, Solid Shaft, 1000 ppr, Push-Pull 7272, 5…30 VDC, Cable RI-10TA0Z4-2K1000-C1M/N26 is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
