Incremental Shaft Encoder - (RI-10T10S-2K5000-C1M)
Turck

Incremental Shaft Encoder, Synchro Flange Ø 58 mm, Solid Shaft Ø 10 mm, 5000 ppr, Push-Pull 7272, 5…30 VDC, Cable

SKU: RI-10T10S-2K5000-C1M

$450.00

List price.

Authorized Dealer
Calibration Available
Nationwide Shipping
Expert Support

Ø 58 mm · Synchro flange · Solid shaft · Cable

Incremental Shaft Encoder — Industrial Line

  • Servo flange, Ø 58 mm
  • Solid shaft, Ø 10mm x 20mm
  • Optical measuring principle
  • Shaft material, stainless steel
  • Protection class IP65 on shaft side
  • -40…+85 °C
  • Max. 12000 rpm (continuous operation 6000)
  • 5…30 VDC
  • Cable connection, 8-pole
  • Push-pull, with inverted signals
  • Pulse frequency max. 300 kHz
  • 5000 pulses per revolution

The Turck Incremental Shaft Encoder, Synchro Flange Ø 58 mm, Solid Shaft Ø 10 mm, 5000 ppr, Push-Pull 7272, 5…30 VDC, Cable RI-10T10S-2K5000-C1M is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
