Radar Sensor - Level Control
SKU: LRS510-10-69-2UPN8-H1141
350…10000 mm · 141.8 x 38 x 50.2 mm, LRS · 6° · PNP/NPN
$1,345.00
List price. Volume pricing available.
Authorized Dealer
Calibration Available
Nationwide Shipping
Expert Support
Radar Sensor — Level Control
- Range: 10 m
- Blind zone: 35 cm
- Resolution: 1 mm
- Cone angle of the radar beam: ±3°
- Distance, level, volume or % output
- Approved according to ETSI 305550-2
- Approved according to FCC/CFR. 47 Part 15.
- Male connector, M12 × 1, 4-pin
- Operating voltage 18…33 VDC
- Switching output switchable between PNP/NPN
- IO-Link
- 4-digit, 2-colored, 14-segment display
- Housing is rotatable by 180° after mounting the process connection
- Process connection G1"
- Pressure resistance -1…16 bar rel.
The Turck Radar Sensor - Level Control # LRS510-10-69-2UPN8-H1141 is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Have questions about this product?
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| EAN | 4047101514476 |
| eCl@ss-Code (V5.1.4) | 27200505 -/- Radar level measurement |
| Customs tariff number | 9026102040 |
| Country of origin | DE |
| Weight | 464 g |
| Function | Radar scanner |
| Design | With display (integrated probe) |
| Construction size | 141.8 x 38 x 50.2 mm, LRS |
| Range | 350…10000 mm |
| Frequency range | 122 - 123 GHz |
| Beam angle | 6° |
| Operating voltage | 17…33 VDC |
| Switching element function | NO/NC programmable |
| Output function | PNP/NPN |
| Communication protocol | IO-Link |
| Electrical connection | Connector, M12 × 1 |
| Process connection | G 1” |
| Housing material | Stainless-steel/Plastic, 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0 PEEK |
| Ambient temperature | -25…+65 °C |
| Protection class | IP67/IP69K |
