Temperature measuring amplifier - 1-channel
SKU: IMS-TI-PT100/24V
Temperature measuring amplifier — 1-channel
$315.30
List price. Volume pricing available.
Authorized Dealer
Calibration Available
Nationwide Shipping
Expert Support
Temperature measuring amplifier — 1-channel
- Connection of temperature probe Pt100
- Output circuit: 0/4…20 mA or 0…10 V
- Accuracy < 0.3% of full scale
- Complete galvanic isolation
- Input reverse-polarity protected
- 6.2 mm width
- UL: Class1, Div2, Group A, B, C, D; GOST
The Turck Temperature measuring amplifier - 1-channel # IMS-TI-PT100/24V is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Have questions about this product?
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| EAN | 4047101349115 |
| eCl@ss-Code (V5.1.4) | 27200206 -/- Transducer (temperature) |
| Customs tariff number | 8543709860 |
| Country of origin | DE |
| Weight | 60 g |
| Signal type | Temperature input |
| Device type | Temperature measuring amplifier |
| Ex version | no |
| Approvals | cULus, GOST |
| Nominal voltage | 24 VDC |
| Number of channels | 1 |
| Electrical connection | Screw terminals |
| Protection class | IP20 |
| Product series | IMS |
