BL compact multiprotocol fieldbus station for Industrial Ethernet — 4 Analog Inputs for Thermocouple Elements

On-machine Compact fieldbus I/O block
EtherNet/IP, Modbus TCP, or PROFINET slave
Integrated Ethernet Switch
10 Mbps / 100 Mbps supported
Two 4-pole M12, D-coded, connectors for fieldbus connection
2 rotary switches for node address
IP67, IP69K
M12 I/O connectors
LEDs indicating status and diagnostics
Electronics galvanically separated from the field level via optocouplers
4 analog inputs for Thermo Couples
Types B, C, E, G, J, K, N, R, S or T (selectable per channel)
Cold-junction compensation via a Pt1000 in special connector

The Turck BL compact multiprotocol fieldbus station for Industrial Ethernet - 4 Analog Inputs for Thermocouple Elements # BLCEN-4M12MT-4AI-TC is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.

Have questions about this product?

Our team can help with product selection, specs, pricing, and application support.

EAN	4047101356755
eCl@ss-Code (V5.1.4)	27250313 -/- Communication interface, passive
Customs tariff number	8536908530
Country of origin	DE
Weight	501 g
Fieldbus Protocol	Modbus TCP, EtherNet/IP, PROFINET
Signal type	Analog input, Temperature
Connection technology signal	M12
Device type	I/O Module, Compact station, Field Logic Controller (ARGEE)
Fieldbus transmission rate	10/100 Mbps
Fieldbus connection technology	2 × M12
Ambient temperature	-40…+70 °C
Protection class	IP67/IP69K

BL compact multiprotocol fieldbus station for Industrial Ethernet - 4 Analog Inputs for Thermocouple Elements
