- Interface for Modbus RTU / ASCII
SKU: BL20-E-GW-RS-MB/ET
With Extended Temperature Range
$374.00
List price. Volume pricing available.
Authorized Dealer
Calibration Available
Nationwide Shipping
Expert Support
Interface for Modbus RTU / ASCII — With Extended Temperature Range
- DIP switch for adjustment of the node address
- Protection class IP20
- 2 x end brackets BL20-WEW35/2-SW
- 1 x end plate BL20-ABPL
- LEDs for display of supply voltage, group and bus errors
- Gateway between the BL20 system and Modbus RTU / ASCII
- RS485 or RS232, configurable
- 9.6 kbps … 115.2 kbps
- Push-in terminals
- Extended temperature range: -25 °C…+60 °C
- Circuit boards with conformal coating
The Turck - Interface for Modbus RTU / ASCII # BL20-E-GW-RS-MB/ET is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Have questions about this product?
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| EAN | 4047101282283 |
| eCl@ss-Code (V5.1.4) | 27250312 -/- Communication interface, active |
| Customs tariff number | 8536504000 |
| Country of origin | CN |
| Weight | 149 g |
| Fieldbus Protocol | Modbus RTU |
| Device type | Gateway |
| Fieldbus transmission rate | 9.6 kbps …115.2 kbps |
| Fieldbus connection technology | Push-in clamps |
| Ambient temperature | -25…+60 °C |
| Protection class | IP20 |
