BL20 Economy Module - 4 Analog Outputs for Current/Voltage
SKU: BL20-E-4AO-U/I
I/O Module · Analog output · Cage clamp terminal · cULus
$507.20
List price. Volume pricing available.
Authorized Dealer
Calibration Available
Nationwide Shipping
Expert Support
BL20 Economy Module — 4 Analog Outputs for Current/Voltage
- Fieldbus-independent
- Electronics and connection technology in one housing
- Connectivity: Push-in terminals
- Protection class IP20
- LEDs indicate status and diagnostic
- Electronics galvanically separated from the field level via optocouplers
- 4 analog outputs
- 0 … 20 mA, 4 … 20 mA, -10 … +10 VDC or 0 … +10 VDC,
- Selectable per channel
The Turck BL20 Economy Module - 4 Analog Outputs for Current/Voltage # BL20-E-4AO-U/I is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Have questions about this product?
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| EAN | 4047101210651 |
| eCl@ss-Code (V5.1.4) | 27250303 -/- Analog I/O module |
| Customs tariff number | 8536504000 |
| Country of origin | CN |
| Weight | 89 g |
| Signal type | Analog output |
| Connection technology signal | Cage clamp terminal |
| Device type | I/O Module |
| Ambient temperature | 0…+55 °C |
| Protection class | IP20 |
| Approvals | cULus |
