BL20 electronic module - 16 Digital Outputs, PNP, 0.5 A
SKU: BL20-16DO-24VDC-0.5A-P
I/O Module · Digital output · Screw terminal, Cage clamp terminal · cULus
$303.30
List price. Volume pricing available.
Authorized Dealer
Calibration Available
Nationwide Shipping
Expert Support
BL20 electronic module — 16 Digital Outputs, PNP, 0.5 A
- Fieldbus and connection technology independent
- Protection class IP20
- LEDs indicate status and diagnostic
- Electronics galvanically separated from the field level via optocouplers
- 16 digital outputs, 24 VDC, max. 0.5 A, PNP switching
The Turck BL20 electronic module - 16 Digital Outputs, PNP, 0.5 A # BL20-16DO-24VDC-0.5A-P is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Have questions about this product?
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| EAN | 4047101137705 |
| eCl@ss-Code (V5.1.4) | 27250302 -/- Digital I/O module (periphery) |
| Customs tariff number | 8523510000 |
| Country of origin | CN |
| Weight | 137 g |
| Signal type | Digital output |
| Connection technology signal | Screw terminal, Cage clamp terminal |
| Device type | I/O Module |
| Ambient temperature | 0…+55 °C |
| Protection class | IP20 |
| Approvals | cULus |
