Inductive Sensor - With Extended Switching Distance
SKU: BI2-EGT08K-AP6X-0.3-RS4T/S1764
M8 x 1 · 2 mm · Flush · Cable with connector, M12 × 1
$240.20
List price. Volume pricing available.
Authorized Dealer
Calibration Available
Nationwide Shipping
Expert Support
Inductive Sensor — With Extended Switching Distance
- M8 × 1 threaded barrel
- Stainless steel, PTFE-coated
- Temperatures up to +100 °C
- DC 3-wire, 10…30 VDC
- NO contact, PNP output
- Pigtail with male end M12 x 1
The Turck Inductive Sensor - With Extended Switching Distance # BI2-EGT08K-AP6X-0.3-RS4T/S1764 is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Have questions about this product?
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| eCl@ss-Code (V5.1.4) | 27270101 -/- Inductive proximity switch |
| Customs tariff number | 8536507000 |
| Country of origin | CH |
| Weight | 31.77 g |
| Design | Threaded barrel |
| Construction size | M8 x 1 |
| Rated switching distance | 2 mm |
| Mounting | Flush |
| Operating voltage | 10…30 VDC |
| Output function | NO contact, PNP |
| Switching frequency | 1.0 kHz |
| Electrical connection | Cable with connector, M12 × 1 |
| Cable length (L) | 0.30 m |
| Housing material | Stainless steel, 1.4427 SO, PTFE-coated |
| Ambient temperature | -25…+100 °C |
| Protection class | IP67 |
| Special features | weldguard |
