8-Channel Digital Hydrometer Kit
SKU: 2001-692
Eight-channel digital hydrometer kit for flooded lead-acid battery cells. Draw electrolyte into the probe and specific gravity (SG) and temperature are determined in 5 seconds. On-board memory for 8 tests × 256 cells each. Test data transfers to the included 8-channel data logger and imports directly into Megger Power DB for full battery condition reporting. Includes Anton Paar digital hydrometer, 8-channel data logger, custom carrying case, and software CD.
List price. Volume pricing available.
8-Channel Digital Hydrometer Kit for BITE Series
The Megger 2001-692 eight-channel digital hydrometer kit for the BITE series measures temperature and specific gravity of flooded battery cells to check a battery's state of charge. It is for use with the Megger BITE 3 battery impedance tester. The hydrometer comes with an eight-channel data logger that stores data for up to 8 tests of 256 cells each. It provides a more accurate indication of a battery's state of charge than a voltmeter.
Battery testers are used in the industrial, commercial, medical, telecommunications, aircraft, power utility, and military industries to detect the health of a battery. They can measure conductance, impedance, voltage, and current, among other parameters. Battery testers are designed for specific types of batteries, such as lead-acid, nickel-metal-hydride (NiMH) and alkaline batteries. Some testers require a load to be applied to the battery during testing, and some do not. A variety of test leads with contacts, probes, clamps, clips, and other connectors can be used to connect a battery to a tester. Since different testers can measure different parameters to calculate battery health, it is important to use the same tester for consecutive tests on a single battery when analyzing changes in battery health over time.
Key Features
- 8 Channel Digital Hydrometer Kit
- For BITE series
- Enhances the Capabilities of the BITE product line
- Designed for unique application situations
- The right tools for battery testing
- Facilities complete battery testing
The Megger 8-Channel Digital Hydrometer Kit # 2001-692 is manufactured by Megger. Valley Instrument Service is an authorized Megger dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Have questions about this product?
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681This product is part of a family with 2 models. Select a model below to view details.
| Model | Price | |
|---|---|---|
Data Logger for Digital Hydrometer Kit 2001-693 | $3,295.00 | View Details → |
Digital Hydrometer KitCurrent 2001-692 | $10,690.00 | Viewing |
