Optifiber Pro Singlemode OTDR V2, w/Inspection & Wi-Fi
Fluke Networks OptiFiber Pro OTDR built for enterprise fiber optic cabling certification testing. It supports copper certification, fiber optic loss, OTDR testing and fiber end-face inspection.
Key Features
- Multiple wavelengths (850, 1300, 1310,1490, 1550 and 1625 nm) support LAN, datacenters, PON, FTTx and outside plant applications.
- Automated setup senses fiber characteristics and sets measurement parameters
- Manual Expert mode allows simple adjustments to automated settings for detailed testing.
- EventMap automatically identifies events including connectors, splices, bends, and splitters
- Gesture-based interface allows fast, in-depth trace analysis View More >
Software and firmware note: Versiv2 firmware 7.2 (October 2026) requires LinkWare PC 12.1 Build 14 or later. Firmware 7 and later is not compatible with original Versiv (V1) mains and remotes, Versiv TFS mains, or the DSX-600, whose final firmware release is 6.14 Build 9. If your team pairs this tester with any of those units, do not update past 6.14. Ask us before updating and we will confirm the right firmware for your kit.
The Fluke Networks Optifiber Pro Singlemode OTDR V2, with Inspection & Wi-Fi OFP2-100-SI is manufactured by Fluke Networks. Valley Instrument Service is an authorized Fluke Networks dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Have questions about this product?
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| Wavelengths | 850 nm +/- 10 nm 1300 nm +35/-15 nm |
| Compatible fiber types | 50/125 µm 62.5/125 µm |
| Event dead zone 1 | 850 nm: 0.5 m typical 1300 nm: 0.7 m typical |
| Attenuation dead zone 2 | 850 nm: 2.5 m typical 1300 nm: 4.5 m typical |
| Dynamic range 3, 5, 6 | 850 nm: 28 dB typical 1300 nm: 30 dB typical |
| Max distance range setting | 40 km |
| Distance measurement range 4, 5, 7, 8, 9, 10 | 850 nm: 9 km 1300 nm: 35 km |
| Reflectance range 4, 5 | 850 nm: -14 dB to -57 dB (typical) 1300 nm: -14 dB to -62 dB (typical) |
| Sample resolution | 3 cm to 400 cm |
| Pulse widths (nominal) | 850 nm: 3, 5, 20, 40, 200 ns 1300 nm: 3, 5, 20, 40, 200, 1000 ns |
| Test time (per wavelength) | Auto setting: 5 sec (typical) Quick test setting: 2 sec (typical) Best resolution setting: 2 to 180 sec FaultMap setting: 2 sec (typical), 180 sec (max) DataCenter OTDR setting: 1 sec (typical at 850 nm), 7 sec (max) Manual setting: 3, 5, 10, 20, 40, 60, 90, 120, 180 sec |
| Wavelengths | 1310 nm +/- 25 nm 1550 nm +/- 20 nm |
| Compatible fiber types | Singlemode |
| OTDR Port Connector | Cleanable APC ferrule with removable SC adapter |
| Event dead zone 1 | 0.7 m (typical) |
| Attenuation dead zone2 | 4m (typical) |
| PON dead zone3 | 30 m (typical) |
| Max distance range setting | 260 km |
| Dynamic range 4, 5 | 1310 nm: 42 dB (typical 1550 nm: 41 dB (typical) |
| Reflectance range4 | -14 to -70 dB (typical) |
| Sampling resolution | 3 cm to 2 m |
| Sampling points | Up to 129000 |
| Pulse widths (nominal) | 5, 10, 30, 50, 100, 300, 500, 1000, 3000, 5000, 10000, 20000 ns |
| Distance uncertainty | +/-(1 + 0.0005*distance + 0.5*resolution) |
| Linearity | ± 0.03 dB/dB |
| Reflectance uncertainty | ±2 dB |
| Test Time (per wavelength) | Auto setting: 5 seconds/wavelength (typical) Auto PON setting: 10 seconds/wavelength (typical) Manual setting: 3, 5, 10, 20, 40, 60, 90, 120, 180 seconds/wavelength Manual PON setting: 3, 5, 10, 20, 40, 60, 90, 120, 180 seconds/wavelength Quick test setting: 3 seconds/wavelength (typical) Best resolution setting: 5 to 180 seconds/wavelength |
| Laser Classification | Class 1 CDRH Complies to EN 60825-2, 3rd Edition |
| Calibration Period | 1 year |
| Magnification | ~ 200X with OptiFiber Pro Display |
| Light source | Blue LED |
| Power source | Versiv mainframe |
| Field of View (FOV) | Horizontal: 425 µm Vertical: 320 µm |
| Minimum detectable particle size | 0.5 µm |
| Dimensions | Approximately 6.75 in x 1.5 in (1175 mm x 35 mm) without adapter tip |
| Weight | 200 g |
| Temperature range | Operating: 32°F to 122°F (0 °C to +50 °C) Storage: -4°F to +158°F (-20°C to +70°C) |
| Certifications | CE (when used with the mainframe) |
| On/Off control | Mechanical switch and a button on the touch screen |
| Output power | 316 µW (-5 dBm) = peak power = 1.0 mW (0 dBm) |
| Operating wavelength | 650 nm nominal |
| Spectral width (RMS) | ±3 nm |
| Output modes | Continuous wave Pulsed mode (2 Hz to 3 Hz blink frequency) |
| Connector adapter | 2.5 mm universal |
| Laser safety (classification) | Class II CDRH Complies to EN 60825-2 |
| Weight | Mainframe with module and battery: 3 lbs, 5 oz (1.28 kg) |
| Dimensions | Mainframe with module and battery: 2.625 in x 5.25 in x 11.0 in ( 6.67 cm x 13.33 cm x 27.94 cm) |
| Battery | Lithium ion battery pack, 7.2 volts |
| Battery life | Eight hour Auto OTDR operation, dual wavelength, no video probe connected, 150 m of fiber |
| Integrated Wi-Fi | Meets IEEE 802.11 a/b/g/n; dual band (2.4 GHz and 5 GHz) |
| Tester Off | Four hours to charge from 10% to 90% capacity |
| Tester On | Six hours to charge from 10% to 90% capacity with the tester on |
| Operating temperature* | -10ºC to 45ºC |
| Storage Temperature | -10ºC to +60ºC |
| Operating altitude | 4,000 m (13123 ft) 3200 m (10,500 ft) with ac adapter |
| Storage altitude | 12,000 m |
| EMC | EN 61326-1 |
