Pressure Transmitter - With Current Output (2-Wire)
SKU: PT15PSIV-1003-I2-H1141
-15…15 psi · 1/4″ NPT-18 male thread · Current output (2-wire) · 7…33 VDC
$194.70
List price. Volume pricing available.
Authorized Dealer
Calibration Available
Nationwide Shipping
Expert Support
Pressure Transmitter — With Current Output (2-Wire)
- Ceramic measuring cell
- Compact and robust design
- Excellent EMC properties
- Pressure range -15…15 psi relative
- 7…33 VDC
- Analog output 4…20 mA
- Process connection 1/4"-18 NPT male thread
- Plug-in device, M12 × 1
The Turck Pressure Transmitter - With Current Output (2-Wire) # PT15PSIV-1003-I2-H1141 is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Have questions about this product?
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| EAN | 4047101496222 |
| eCl@ss-Code (V5.1.4) | 27200614 -/- Piezoresistive sensor (absolute and relative pressure) |
| Customs tariff number | 9026204000 |
| Country of origin | CH |
| Weight | 82 g |
| Design | Without display |
| Process connection | 1/4″ NPT-18 male thread |
| Pressure type | Relative pressure |
| Pressure range bar | -1.03…1.03 bar |
| Pressure range psi | -15…15 psi |
| Operating voltage | 7…33 VDC |
| Electrical output | Current output (2-wire) |
| Current output | 4…20 mA |
| Electrical connection | Connector, M12 × 1 |
| Housing material | Stainless-steel/Plastic, 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0 |
| Material pressure transducer | Ceramic Al₂O₃ |
| Medium temperature | -40…+125 °C |
| Ambient temperature | -30…+85 °C |
| Protection class | IP67 |
| Approvals | CE, Metrological certification (RUS), cULus |
This product is part of a family with 126 models. Select a model below to view details.
| Model | Price | |
|---|---|---|
PT1VR-1001-I2-H1143 | $194.70 | View Details → |
PT1VR-1001-U1-H1141 | $194.70 | View Details → |
PT1VR-1001-U1-H1143 | $194.70 | View Details → |
PT1VR-1121-U6-DT043P | $194.70 | View Details → |
PT1VR-1001-IOL-H1141 | $243.40 | View Details → |
PT1VR-1013-IOL-H1141 | $243.40 | View Details → |
PT1VR-1003-IOL-H1141 | $251.80 | View Details → |
PT0.05V-1503-I2-H1143/D840 | $429.10 | View Details → |
PT0.2V-1003-I2-H1143 | $194.70 | View Details → |
PT0.2V-1004-I2-H1143 | $194.70 | View Details → |
