Flow Rate Monitoring - Inline Sensor with Integrated Processor
SKU: FTCI-N3/4D19A4P-2ARX-H1160
Flow rate measurement · liquids · Inline · 3/4″ NPT
$1,209.50
List price. Volume pricing available.
Authorized Dealer
Calibration Available
Nationwide Shipping
Expert Support
Flow Rate Monitoring — Inline Sensor with Integrated Processor — Relay Output 24 VDC NO
- Compact inline flow sensor
- Calorimetric principle
- Monitoring of flow rate
- Monitoring of the medium temperature
- For water/glycol mix
- Parametrized via button
- Protected by software code
- Hysteresis flow 0.4 … 1.9 l/min
- Hysteresis temp 1…10 °C
- Temperature monitoring -10…95 °C
- Switch-on/switch-off delay 0…50 s
- 2 relay switching outputs
- Switching outputs 24 VDC NO
- Switchpoints freely adjustable
The Turck Flow Rate Monitoring - Inline Sensor with Integrated Processor # FTCI-N3/4D19A4P-2ARX-H1160 is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Have questions about this product?
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| EAN | 4047101291254 |
| eCl@ss-Code (V5.1.4) | 27200403 -/- Flow meter (mass, thermal) |
| Customs tariff number | 8536504000 |
| Country of origin | CN |
| Weight | 569 g |
| Function | Flow rate measurement |
| Design | Inline |
| Process connection | 3/4″ NPT |
| Medium | liquids |
| Detection type | Calorimetric |
| Operating voltage | 21.6…26.4 VDC |
| Output function | NO contact, Relay output |
| Electrical connection | Connector, M12 × 1 |
| Sensor material | Stainless steel |
| Housing material | Plastic, PBT |
| Medium temperature | -10…+95 °C |
| Ambient temperature | -20…+60 °C |
| Protection class | IP54 |
