Actuator and Sensor Junction Box - 4 Port
SKU: VB 40-B1161
4 · Male, 7/8″-16UN, Side exit · 48 V · CSA, RoHS
$164.00
List price. Volume pricing available.
Authorized Dealer
Calibration Available
Nationwide Shipping
Expert Support
Actuator and Sensor Junction Box — 4 Port
- M12 Eurofast Junction Box
- 4 ports
- Side exit 7/8" Minifast home run connector
- Plastic housing
The Turck Actuator and Sensor Junction Box - 4 Port VB 40-B1161 is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Have questions about this product?
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| Customs tariff number | 8536908530 |
| Country of origin | MX |
| Weight | 327.5 g |
| Application | Signal |
| Number of ports | 4 |
| I/O Port | Female, M12 × 1 |
| Signals Per Port | 1 |
| Homerun connector | Male, 7/8″-16UN, Side exit |
| Housing material | Plastic |
| Voltage | 48 V |
| Current Per Port | 4 A |
| Approvals | CSA, RoHS |
| Connector Series | M12 eurofast |
