Hazardous Location Junction Box - 8 Port
SKU: P-8MBV12-4-CSV19
8 · Male, M23 × 1, Top exit · 48 V · FM Div.1
$315.60
List price. Volume pricing available.
Authorized Dealer
Calibration Available
Nationwide Shipping
Expert Support
Hazardous Location Junction Box — 8 Port
- M12 Eurofast Junction Box
- 8 ports
- Top exit M23 Multifast home run connector
- Plastic housing
The Turck Hazardous Location Junction Box - 8 Port P-8MBV12-4-CSV19 is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Have questions about this product?
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| Customs tariff number | 8536908530 |
| Country of origin | DE |
| Weight | 409.44 g |
| Application | Hazardous Location |
| Number of ports | 8 |
| I/O Port | Female, M12 × 1 |
| Signals Per Port | 1 |
| Homerun connector | Male, M23 × 1, Top exit |
| Housing material | Plastic |
| Voltage | 48 V |
| Current Per Port | 3 A |
| Approvals | FM Div.1 |
| Connector Series | M12 eurofast |
