Powerfast Receptacle - Front Mount
SKU: GKDF 40-1M/14.75/NPT
View all 8 variants in this family
Female, 1 3/8″-16 UN · 4 · Brass, CuZn, Nickel-plated · 35 A · CE, RoHS, UL 2237
$75.40
List price. Volume pricing available.
Authorized Dealer
Calibration Available
Nationwide Shipping
Expert Support
Powerfast Receptacle — Front Mount
- 1 3/8″ female receptacle
- Mounting thread: 1/2″-14 NPT
The Turck Powerfast Receptacle - Front Mount GKDF 40-1M/14.75/NPT is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Have questions about this product?
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| Customs tariff number | 8536694020 |
| Country of origin | MX |
| Weight | 1.1 g |
| Application | Power (>11 Amps) |
| Connector A | Female, 1 3/8″-16 UN |
| Number of contacts | 4 |
| Housing material/finish | Brass, CuZn, Nickel-plated |
| Mounting orientation | Front mount |
| Mounting thread | 3/4″-14 NPT |
| Voltage | 600 V |
| Current | 35 A |
| Protection class (When coupled) | IP67, IP68, IP69K |
| Approvals | CE, RoHS, UL 2237 |
| Connector Series | 1 3/8" powerfast |
