Actuator and Sensor Junction Box - 8 Port, M12 Eurofast I/O Ports, Side Exit M23 Male Home Run, 1 Signal per Port, Plastic Housing
SKU: 8MB12Z-4P2-CS12H
8 · Male, M23 × 1, Side exit · 30 V · UL Listed, RoHS
$179.70
List price.
Authorized Dealer
Nationwide Shipping
Expert Support
Actuator and Sensor Junction Box — 8 Port
- M12 Eurofast Junction Box
- 8 ports
- Side exit M23 Multifast home run connector
- Plastic housing
The Turck Actuator and Sensor Junction Box - 8 Port, M12 Eurofast I/O Ports, Side Exit M23 Male Home Run, 1 Signal per Port, Plastic Housing 8MB12Z-4P2-CS12H is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Have questions about this product?
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| EAN | 4047101291049 |
| eCl@ss-Code (V5.1.4) | 27250313 -/- Communication interface, passive |
| Customs tariff number | 8536908530 |
| Country of origin | MX |
| Weight | 310 g |
| Application | Signal |
| Number of ports | 8 |
| I/O Port | Female, M12 × 1 |
| Signals Per Port | 1 |
| Homerun connector | Male, M23 × 1, Side exit |
| Housing material | Plastic |
| Voltage | 30 V |
| Current Per Port | 2 A |
| Approvals | UL Listed, RoHS |
| Connector Series | M12 eurofast |
