Actuator and Sensor Junction Box - 8 Port
SKU: 8MB12Z-4-CS12H
8 · Male, M23 × 1, Side exit · 250 V · UL Listed, RoHS
$139.00
List price. Volume pricing available.
Authorized Dealer
Calibration Available
Nationwide Shipping
Expert Support
Actuator and Sensor Junction Box — 8 Port
- M12 Eurofast Junction Box
- 8 ports
- Side exit M23 Multifast home run connector
- Plastic housing
The Turck Actuator and Sensor Junction Box - 8 Port # 8MB12Z-4-CS12H is manufactured by Turck. Valley Instrument Service is an authorized Turck dealer offering full sales support, NIST-traceable calibration, and expert technical assistance.
Have questions about this product?
Our team can help with product selection, specs, pricing, and application support.
Contact Us or Call (661) 327-8681| EAN | 4047101666670 |
| eCl@ss-Code (V5.1.4) | 27250313 -/- Communication interface, passive |
| Customs tariff number | 8536908530 |
| Country of origin | MX |
| Weight | 305.03 g |
| Application | Signal |
| Number of ports | 8 |
| I/O Port | Female, M12 × 1 |
| Signals Per Port | 1 |
| Homerun connector | Male, M23 × 1, Side exit |
| Housing material | Plastic |
| Voltage | 250 V |
| Current Per Port | 2 A |
| Approvals | UL Listed, RoHS |
| Connector Series | M12 eurofast |
