MSI (Measurement Systems International)
US manufacturer of crane scales and wireless weighing solutions — CellScale, Port-A-Weigh series.
Browse MSI (Measurement Systems International) Products
105 products across 4 product lines
Featured MSI (Measurement Systems International) Products
Popular instruments and equipment
MSI-6360 100K TRANS-WEIGH F/A. RADIO LINK, SCALECORE SOFTWARE, 12 VDC BATTERY, SWIVEL HOOK
The MSI-6360 Trans-Weigh is an industrial crane scale designed to withstand high temperatures. The IP66 cast aluminum enclosure protects sensitive components to ensure safety and accurate weights. Able to meet or exceed industrial safety requirements, the MSI-6360 features a 200% Safe and 500% Ultimate Safety Factor that minimizes accidents from overloading. • 12-volt rechargeable battery and universal 115/230 VAC, 50/60 Hz battery charger (NA plug standard) • Top lifting eye or shackle with Crosby (or equivalent) 360° thrust-bearing swivel hook • RF modem install for connectivity to MSI-8000, MSI-8000HD RF, MSI-8004HD RF remote display, TranSend and LaserLight2 remote display. Typically, 100 to 300 ft, line of sight;for longer range consult factory. • Meets or exceeds OSHA, ANSI, ASME and other safety design standards (5:1 Ultimate Safety Factor)
MSI-4260C 100,000 lb Swvl Hook 12V Battery LED Dual Color Display Non-CE
The MSI-4260 Port-A-Weigh features ScaleCore technology and has a capacity of 500 to 100,000 pounds (250 to 50,000 kilograms). The IP66 marine-grade cast aluminum enclosure protects and secures sensitive electronics from harsh conditions. • Multi-color LED display • Top lifting eye or shackle with Crosby (or equivalent) 360° thrust-bearing swivel hook • 12 volt rechargeable battery and universal 115/230 VAC, 50/60 Hz battery charger (NA plug standard)
MSI-9600HT 70K FINAL Assembly TORQUE RESISTANT
The MSI-9600HT Hi-Torque Port-A-Weigh Plus has two versions to meet the needs of heavy-capacity weighing applications. Capacities range from 10,000 to 70,000 pounds (±0.1% accuracy) or 100,000 to 200,000 pounds (±0.2% accuracy). The unit of measurement can be selected between pounds and kilograms for both versions. • Multi-color LED display • 12 volt rechargeable battery and universal 115/230 VAC, 50/60 Hz battery charger (NA plug standard) • Shackle is optional and Crosby fixed hook provided as standard • Hi-torque load train designed for use with powered rotation
MSI-3460C 15K x 5 lb Challenger 3 Crane Scale, WIFI, Non-CE, Non-NTEP, Batt Power
The MSI-3460 Challenger 3 digital crane scale has a capacity of 15,000 pounds with a ±0.1% accuracy. A large multicolored LED digital display can show up to five digits and includes brightness control, zero, tare, auto-off and auto-sleep functions. Able to withstand extreme conditions, the MSI-3460 features a 360-degree non-bearing swivel hook for optimal operation. • Multi-color LED display • Top lifting eye and bottom swivel hook • Crosby or equivalent with 360° non-bearing swivel hook • Lb/kg switch selectable • Six volt rechargeable battery and universal 115/230 VAC, 50/60 Hz battery charger (NA plug standard) • Meets or exceeds OSHA, ANSI, ASME and other safety design standards (5:1 Ultimate Safety Factor) • NTEP Certified (250 to 10,000 lb capacities)
Dyna-Clamp Line Tensiometer for 1.0in Rope 12,500lbs
The MSI Dyna-Clamp tension meter has a wire rope engagement site window to help ensure accurate tension readings. The MSI Dyna-Clamp features an easy-turn power screw, to make measuring wire rope tension simple and effortless, even in difficult environments. • Dual line LCD display • Two user-programmable function keys • IP65 anodized aluminum frame • RS-232 port • Up to eight factory calibrations included at no additional cost
MSI-7300WIFI 100000 Lb Final Assembly. Dyna-Link 2 Digital Tension Dynamometer With WIFI. 4/IP65 Anodized Corrosion-Resistant Finish. Has 5 Digit LCD Display and LED Annunciators.
Dyna-Link 2 is lighter and more portable than its predecessor. It interfaces with industry-standard Crosby shackles and a variety of accessories and options, including wireless connectivity with the MSI-8000 and 8000HD RF remote display. Long-range viewing is enhanced by a large six-digit, 1 inch (25.4 mm) LCD display with resolution settings up to 5,000 divisions and precision accuracy over a wide range of capacities.Dyna-Link 2 is constructed of high-grade, aircraft-quality aluminum with an anodized finish and gasket sealing to ensure NEMA 4/IP65 rated environmental protection. Peak digital processing with low power consumption provides up to 300 hours of operation from standard common batteries during typical use. The optional MSI-8000 RF remote display provides full-function remote control of Dyna-Link 2 features up to distances of 100 feet (30m). An integrated serial port offers interface capabilities with data collection devices. • LCD display • Two C-cell alkaline batteries for capacities up to 10,000 lb (5,000 kg) • Two D-cell alkaline batteries for capacities 25,000 lb (12,500 kg) and above
